Class：

SK best series

Print technology：

Drop-on-demand Piezo electric

Printing head：

USA POLARIS BRAND 5pcs heads （Spectra Polaris 512/15 pl)                                         Quality of print head is optional.4/5/6/7/10etc,.

Printing size：

3.0 M*1.8M

Print high：

10cm   (the max. printing thickness can be made up to 24cm)

Resolution：

1440dpi max

Production Efficiency:

Max. 23sq.m/1hour

Locating mode：

Raster /servo

Color：

C M Y K W or CMYK W+ LC+LM

Printing range:

Glass, Wood, KT board; PVC board; Plexiglass board; Ceramic board, tile; metal board; leather and all the roll to roll material like flex banner, mesh, one way vision, vinyl etc

Drying system ：

UV lamp

File format：

TIFF, Postscript 3, JPEG, EPS, PDF

Working process：

software for windows XP

Rip：

Photoprint /maintop

Power supply：

50Hz/60Hz 220v(10%)20A

Operation environment

(Temperature )18-26      (Humidity ) 40%-70%

Packing Dimension：

5.2 m*2.3m*1.66m

Weight：

1600 Kg
