packaging DetailsIn well protected carton or wooden box with pallets.
<p vertical-align:baseline;color:#333333;background-color:#ffffff;"="" style="box-sizing: border-box; margin-top: 0px; margin-bottom: 10px; color: rgb(97, 95, 95); font-family: "Times New Roman", Arial, Helvetica, sans-serif; font-size: 14px; white-space: normal; background-color: rgb(240, 237, 234); font-weight: 700;">
Moduel | BSM250P-60 | BSM260P-60 | BSM270P-60 | BSM280P-60 | BSM285P-60 |
Rated Maximum Power at STC | 250 | 260 | 270 | 280 | 285 |
Open Circuit Voltage(Voc/V) | 37.66 | 37.98 | 38.30 | 38.85 | 39.05 |
Maximum Power Voltage(Vmp/V) | 29.94 | 30.55 | 31.21 | 31.88 | 32.13 |
Short Circuit Current(Isc/A) | 8.92 | 9.04 | 9.16 | 9.33 | 9.53 |
Maximum Power Current(Imp/A) | 8.35 | 8.51 | 8.65 | 8.78 | 8.91 |
Module Efficiency(%) | 15.29 | 15.90 | 16.51 | 17.12 | 17.42 |
Power Tolerance | -0~+3% | ||||
Standard Test Condition(STC) | Irradiance 1000W/m2,Cell Temperature 25℃，Air Mass1.5 | ||||
Detailed&Production
> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
