Quick Details
Place of Origin:
China (Mainland)
Product Description
Basic Info
- Model NO.: 4LZ-4.0Z
- Application: Rice, Wheat, Rape
- Harvest method: Cutting
- Transmission: Hard Shaft
- Certification: SGS, ISO9001:2008, CE
- Condition: New
- Engine: 68kw
- Weight: 3000kgs
- Trademark: WISHOPE
- Specification: CE SGS ISO
- HS Code: 8433510090
- Type: Vertical Cut Harvester
- Power Source: Diesel
- Drive Type: Gear Drive
- Portable Harvester Type: Self Propelling
- Color: Yellow
- Application Field: Agriculture
- Cutting Width: 2.0m
- Rice Unloading Auger: 360 Degree Optional
- Transport Package: Standard
- Origin: Sichuan
Product Description
Copy Kubota 360 Degree Rice Unloading Auger Grain Combine Harvester | Main Parameter: |
| No. | Item | Unit | Specification |
| Weight | (KG) | 3000 |
| Feeding Capacity | kg/s | 4.0 |
| Dimension | Length | (mm) | 5100 |
| Width | (mm) | 2600 |
| Height | (mm) | 2450 |
| Engine | Model | / | 498BT/BZT/L,4C6-88M22 |
| Rated Power | (kw/hp) | 68/88,55/75(Alternative) |
| Engine type | / | Water cooled,4-Cylinder,DI-Injection Vertical Diesel,Turbocharged Engine |
| Rated Rotating Speed | (r/min) | 2400 |
| Full Tank Capactiy | L | 70 |
| Driving system | Rubber Track | (mm) | 400(450/500)*90*48 |
|
| Gearshift Type | / | Hydraulic+HST(3F,3R) |
| Type of Brake | / | By foot |
| Steering | (mm) | Clutch and Brake |
Min grounded
clearance | (mm) | 280 |
| Cutting Header | Pickup Reel | Type | Eccentric tooth (Off-centre) |
| Diameter(mm) | 900 |
| Nos | 5 |
| Type of Header Auger | / | Telescopic Screw Conveying |
| Type of Blade | / | V Type/ Left and Right |
| Height Adjustment | / | Hydaulics |
| Cutting Bar Length | (mm) | 2000 |
| Thresher | Threshing Type | / | Spike Tooth Axial flow |
| Threshing Cylinder Size | Diameter*Length(mm) | 620*1700 |
| Rethresher | / | Blade Rotation |
| Concave sieve | / | Grid*4 |
| Vibrating sieve | / | Adjustable Sieve/Meshing
Sieve/Hole Seive(Optional) |
| Fan | Type | Swirl |
| Diameter(mm) | 405 |
| Nos | 4 |
Grain
Storing | Option 1 | Big Grain Tank with Unloading Auger,Capacity(L):1500 |
| Option 2 | Small Tank Manual Operation |
Rice Unlaoding
Auger | Option 1 | 90Degree Rice Unloading Auger (Standard) |
| Option 2 | 360Degree Rice Unloading Auger |
| Productivity | (hm2/h) | 0.4-0.75 |
![Copy Kubota 360 Degree Rice Unloading Auger Grain Combine Harvester]()
![Copy Kubota 360 Degree Rice Unloading Auger Grain Combine Harvester]()
![Copy Kubota 360 Degree Rice Unloading Auger Grain Combine Harvester]()
Company Introduction:WuHan Wishope is one branch company of Wishope International Group Limited, mainly engaged agricultural machinery production and trading.Our business contains: Sales of all kinds of farming machines and related spare parts, specially professionally in full feeding crawler combine harvester, rice transplanter, tractor & power tiller, and also spare parts of brandedd farming machines such as Kubota, YanMar, Daedong, John Deere, Mubota, Xingguang.Major market covers South East Asia, Middle East, as well as Southern Asia. With rich experience of exporting and excellent before-sales and after-sales service. It brings us very good reputation.
FAQ:1.Q: What is the warranty of the agricultural machinery?
A: One year guarantee for whole machine (except quick-wear parts), engine model and gear box.
Tips: we usually suggest the buyer order some quick-wear parts separately.
2.Q: Is there any option for your combine?
A: Yes, option parts such as: rubber track, grain tank and type of grain unloading
3.Q: What is your delivery time?
A: Normally, it takes 15-20days to delivery after your deposit receipt or L/C at sight
4.How many harvesters can be loaded in one container?
1)20 Feet Container loads:
For Combine: 5 sets 4LZ-0.5; 8sets 4LZ-0.8; 1set 4LZ-1.2; 1set 4LZ-2.2; 1set 4LZ-3.0; 1set 4LZ-4.0/4.5
2) 40 High Cube Container loads:
For Combine: 11sets 4LZ-0.5; 20sets 4LZ-0.8; 4sets 4LZ-1.2; 4sets 4LZ-2.2, 3sets 4LZ-3.0, 3sets 4LZ-4.0/4.5
5.Q: What is the payment item?
A: Irrevocable L/C at sight or 30% T/T in advance and balance against B/L copy.
6.Q: What is the after-sales service?
A: Every year we send our engineer and after-service people to local market two times, to assist our sales agent training staff, marketing, advertising, maintaining and repairing the machine during the harvesting season.
7.Q: Is OEM or ODM service acceptable?
A: OEM service is no problem, if you have any special requirement about the machine, please kindly inform us, our engineer department will study and offer your suitable solution.
