20hp small tractor mini diesel tractor price with big discount-- Heze Luya Group Work Win Co.,Ltd.

China fully automatic hydraulic baling press

1.Farm tractors price adopt renowned directly injection vertical water cooled 4-stroke YTO/YUCHAI engine.

2.China cheap tractors cltuch:Single,Dry,Dual Stage Type.

3.Our farm tractors wheel tread F/R(mm):1200-1500(4 WD)/1400(2 WD),1300-1600.

4.PTO:φ38,8teeth φ35,6teeth,Speed:540/760.Linkage:II Rear Mount 3-point Linkage.

We can produce customized all sorts of small, medium, large tractor, diesel type, electric type can be customized production, walking tractor 5 HP - 20 HP, medium-sized tractor 15 HP - 110 HP tractor, and 120 HP to 140 HP large farm tractors,and We can supply series farm implements, such as disc plough, harrow, loader, backhoe, trailer etc you want. But firstly, tell us your preferred horsepower tractor.


NOTE:The price is For 18Hp tractor:

model	SIN150	SIN154	SIN184
Engine model	1100NM	1100NM	1105NM
Engine model	Single cylinder, Horizontal, Four Stroke, Direct Injection
Rated Rev.(rpm)	2200
Rated traction force(KN)	3.2	3.5	4.1
Front wheel tread(mm)	730-780 adjustable
Rear wheel tread(mm)	700~800 adjustable
Front wheel tire	5.00-12	5.00-12	5.00-12
Rear wheel tire	6.50-16	7.50-16	7.50-16
Gear box	F6+R2
Clutch	One stage, single disc, dry, constant mesh
Starting Method	Electric, 12V starter
Rated Power(KW)	11.03	11.03	13.2
Wheel base(mm)	1080	1150	1150
Overall size (mm)	17609101000	18509801100	18509801100
40HQ quantity (with tiller and plough)	42 sets	32 sets	32 sets
One set package (plywood)	225014501460

Factory supply new model 20-40hp mini garden tractor price

Electric start, 2 * 2 wheel, half-rack, belt drive, hydraulic lifting, dual valve, double pipe, double-plate dry clutch, mechanical steering wheel, basic hood (D), 400-10 / 650- 16 tires, 45A battery,differential mechanism in gear-box.
