Condition:NeW Type:Wheel Tractor By wheel:4WD
Usage:Farm Tractor Drive Type:Gear Drive Power(W):29.4KW
Certificate:ISO Brand Name:Dongfeng Model Number:DF404
Place of Origin:Jiangsu, China (Mainland) Color:Red
After-sales Service Provided:Overseas service center avail
Packaging Details:standard package, 40HC container can hold 4 units
Port:Qingdao
Lead Time :Shipped in 20 days after payment
ctor | Model | DF-404 | |
Drive Type | 4WD | ||
Overall Dimensions | 3354×1500×1620(Height to steering wheel) | ||
Wheel Track(mm) | Front | 1200 | |
Rear | 1100(Usually use),1200,1300,1400 | ||
Wheel Base(mm) | 1818 | ||
Ground | Under Front Axle | 378 | |
Under Rear Axle | 405 | ||
Rated Traction | In Paddy Fields | 5760 | |
In Dry Fields | 7960 | ||
Construction Mass(Kg) | 1485 | ||
Min. Turning Radius(m) | 3.2 | ||
Theoretical | Forward | 1.75,2.88,4.63,6.22,9.05,14.90,23.98,32.21 | |
Reverse | 2.30,11.92 | ||
Engine | Model | ZN490T | |
Type | 4-cylinder,Upright inline cylinder | ||
Rated Power(Kw/hp) | 29.4/40.0 | ||
Rated Fuel Consumption(g/kw/h) | ≤275 | ||
Rated Speed(rpm) | 2400 | ||
Bore×Stroke(mm) | 90×100 | ||
Total Displacement(L) | 2.543 | ||
Drive | Clutch | Linkage type dual-function clutch | |
Gear Box | (4+1)×2,plannar 3-shaft for main transmission | ||
Main Drive | One Pair of Spiral Bevel gears | ||
Differential | Bevel Gear | ||
Differential Lock | Jaw Lock | ||
Final Transmissions | Spur Gear,External Gearing | ||
Travelling | Tyre | front | 7.5-16 |
rear | 12.4-24 | ||
Steering Gear | Hydraulic streering | ||
Brake | Disk type | ||
Working | Hydraulic | Lifting Capacity at | 665 |
3-point Suspension | Category:I | ||
P.T.O.Shaft | Rotating | 540/1000 | |
Spline size | 6-φ35 Rectangular spline | ||
Our main product lines: tractor series, agricultural cultivating machinery series, spraying series, harvesting machinery series, post-processing machinery series, casting and forgings series. Our farm implements could match with domestic tractor (FOTON, YTO), and foreign famous brand tractor (JOHN DEERE, NEW HOLLAND, KUBOTA etc.)
We have a multilingual team, and many big branch factories. A regional market presence-including southeast Asia, Indonesia, Russia, Spain, Chile, Brasil, Australia etc.
