Basic Info.
Model No.: 109B/109
Export Markets: Global

Additional Info.
Trademark: QH
Packing: Carton
Standard: SGS
Origin: China
Production Capacity: 10000sets

Product Description
Features:
Balanced
Single seal
Multiple springs rotating
PTFE wedge ring as auxiliary sealing

Advantages:
Ideal seal for standardizations
For high pressure application
Excellent compensation ability
Extended service life
Installation faults are avoided, cost-effective
No damage caused by dirt entered during assembly
Straightforward and easy installation due to pre-assembled unit (reduced down-times)
Individual adaptation to pump design possible
Customer specific versions available

Applications:
Chemical industry
Special rotating equipment
Pharmaceutical industry
Water and waste water technology
Petrochemical industry
Pulp and paper industry
Refining technology
Operating range

Pressure: ≤ 5MPa
Temperature: ≤ 200° C
Rotation speed: ≤ 5000r/min

Materials:
Metal parts: 316, 304, 2Cr13
Secondary seal: Silicon carbide or hard alloy.
