Condition: New
Type: Farm Cultivator
Power Type: Diesel
Certification: ISO9001:2000
Use: Cultivator
Place of Origin: Shandong, China (Mainland)
Brand Name: ALI DISC HARROW
Model Number: 1LYQ-220
Weight: 130kg
After-sales Service Provided: Engineers available to service machinery overseas
| Packaging Details: | iron packing |
|---|---|
| Delivery Detail: | Shipped in 15 days after payment |
Model | unit | 1LYQ-220 | 1LYQ-315 | 1LY-320 | 1LY-325 | 1LY-330 | 1LY-425 | 1LY-525 | 1LY-625 |
Working width | m | 0.4 | 0.45 | 0.6 | 0.75 | 0.90 | 1.0 | 1.25 | 1.5 |
Working depth | mm | 200 | 180 | 200 | 250 | 300 | 250 | 250 | 250 |
Diameter of disc | mm | 500 | 450 | 500(510) | 650(710) | 710 | 650(710) | 650(710) | 650(710) |
Q’ty of disc | 2 | 3 | 3 | 3 | 3 | 4 | 5 | 6 | |
Total Weight | kg | 200 | 210 | 220(230) | 450(480) | 510 | 510(540) | 600(640) | 650 (670) |
Matched power | hp | ≥18 | ≥25 | 25~40 | ≥50 | 70 | 80~100 | 100~120 | 120~160 |
Linkage | (Standard three-point mounted) | ||||||||
Shandong yucheng Ali Disc Harrow Co.,Ltd Welcome your inquiry!
Your business is our success! Any questions please just feel free to contact me <span style="margin: 0px; padding: 0px; border: 0px; font-style: inherit; font-variant: inherit; font-weight: inherit; font-stretch: inherit; font-size: 14pt; line-height: 28px; font-family: Arial; vertical-ali
