Product Description
Applicable materials
Cloth, leather, fur, acrylic, plexiglass, wooden board, plastic, rubber,bamboo, products, resin and other non-metal materials.
Applicable industries
The machine is suitable for cutting of garment and leather, package and printing, advertisement decoration, building upholster, art gift, computer embroidery, paper products, acrylic board industries, etc..
Technical parameters
Laser power: | 60-130W(optional) |
Laser Type: | Hermetic CO2 glass tube |
Power supply: | AC220/110,±10%,50/60HZ |
Working area : | 900x600mm |
Max moving speed: | 0-40000mm/Min |
Worktable: | Lifting aluminium blade/ honey comb(optional) |
Locating precision: | <0.01mm |
Mini Shaping character: | character: 2x2mm, letter:1x1mm |
Operating temperature: | 5-35℃ |
Resolution ratio: | ≤4500DPI |
Control configuration: | DSP |
Data transfer interface: | USB(offline) |
System environment: | windows2000/XP/Vista/Win7/win8 |
Cooling way: | water cooling and protection system |
Graphic format supported:
| the files which CorelDraw, Photoshop, AutoCAD can identify(BMP, GIF,JPGE, PCX, TIFF,PLT, CDR.DMG etc.) |
ompatible software: | CorelDraw, AutoCAD |
Cutting thickness: | 0-20mm(depends on different materials) |
Color separation: | up to 256 colors |
Protection when water supply stops | yes |
Net weight/ gross weight | 260kg/320kg |
Machine dimension: | 1650x1330x1220mm |
Optional parts:
| high grade cooling system/double-head/cylinder rotary axis/irregular rotary axis |
| Packaging Details: | plywood case worthy of sea voyage, non metal materials 80w laser engraving machine 690 |
|---|---|
| Delivery Detail: | 7 days |
Our Services
1. engineers available for overseas service;
2. 24 hours online support;
3. fast feedback to any questions and problems related to machine quality; prompt action for confirmed quality problem;
4. patience and carefulness;
5. never stop providing technical support and parts to our customers.
